Florida Keys Bridge #4 Tavernier Creek Bridge MM91.0

Tavernier Creek Bridge MM91.0
December 5, 2012, Keith Nelson, Rob Hickman
15 Ft Vertical clearance, 320 Ft long

Day #2 Official Starting Point - Mile Marker 103.1
December 5, 2012

Harriette's Cafe
December 5, 2012, Keith Nelson, Rob Hickman

Local painter and arts organizer Cris Sandifer poses in front of her painting which depicts an original Flagler mile marker.

December 5, 2012, Original Flagler Mile Marker.

Public Mural Commemorating Overseas Railroad Centennial
December 5, 2012, Keith Nelson, Cris Sandifer, Rob Hickman


Structure number: 900127
Location: TAVERNIER KEY (MM 90.8)
Purpose: Carries two-lane highway over waterway
Route classification: Principal Arterial - Other (Rural)
Length of largest span: 64.0 ft. [19.5 m]
Total length: 319.9 ft. [97.5 m]
Roadway width between curbs: 35.1 ft. [10.7 m]
Deck width edge-to-edge: 44.0 ft. [13.4 m]
Vertical clearance below bridge: 14.8 ft. [4.5 m]
Owner: State Highway Agency
Year built: 1993
Historic significance: Bridge is not eligible for the National Register of Historic Places
Design load: MS 18 / HS 20
Number of main spans: 5
Main spans material: Prestressed concrete
Main spans design: Stringer/Multi-beam or girder
Deck type: Concrete Cast-in-Place
Wearing surface: Integral Concrete (separate non-modified layer of concrete added to structural deck)

Click here for the full Florida Keys Trip Log
